DS |
ML4 |
ML6 |
| X-OMR |
560 |
530 |
530 |
| Y-OMR |
637 |
610 |
610 |
| X (Customer) |
528 |
482 |
466 |
| Y (Customer) |
601 |
564 |
556 |
1. Please note that X/Y Customer is the surface available for the customer pcbs.
2. Please note the quantity of pcbs (in the surface available for the customer pcbs) will change in function of the dimension of each pcb.
